MSizer compact, extend and giant
MSizer as optimal solution for any screening/classification
The MSizer compact, extend and giant models set a new standard for screening bulk materials. The units differ in the screen deck length and are all available in working widths of 0.5, 1.0, 1.5, 2.0 and 3.0 meters. The MSizer compact is driven by one vibration motor and generates an elliptical movement to screen incoming material. The MSizer extend and giant are set into linear movement by two vibration motors.The MSizer giant is the world's largest sizer that can realize very high performance as a single machine. Each machine is available with 1 to 6 screen decks to meet your individual screening and fraction requirements. The MSizer excels in screening animal feed, wood pellets, fertilizer, salt, minerals, stones, and earth, building material products and sugar.
Good to know
Functionality
The Mogensen MSizer system consists of 2 to 6 screen decks, one above the other, at different inclinations, with mesh sizes becoming finer on the lower decks. The machine housing is set in motion by vibration motors or judge exciters. While the finer grain of the infeed material immediately flows almost vertically through the course meshes of the upper decks, the coarser grains are screened out of the material flow. This eliminates material “surfing” on top of oversized material and never reaching the screening surface and properly screened.
Because of the increasing screen deck inclination from top to bottom deck, the mesh openings perform as a smaller mesh size. In comparison to conventional sifters and flat screens, the mesh sizes on a MSizer can be selected larger while maintaining good separation efficiency. The separation of different particle sizes from the material flow quickly using several screen decks and the larger mesh widths of the screen cloth reduces wear and ensures long screen life and high throughput.
Benefits
Maximum Efficiency: Precise separation ensures excellent process results.
High Performance: With the Mogensen sizer technology, higher output in a small footprint is possible when compared to other screening technologies. Flexibility in the design of working width (0.5m - 3.0m), screen deck length (1.30m - 3.30m) and number of screens allow the most efficient layout.
Compact Design: Efficiency and Performance of Sizer technology gives you more screening in less square feet (in some cases only 20% of the space required compared to conventional screening technology).
Maximum Plant Availability: Safe operation due to fail-safe control and vibration monitoring. Long service life and no clogging of the screen cloth due to the Sizer principle.
High safety: Maximum operational reliability due to FEM-optimized and robust design.
Simple maintenance: Quick screen changes by access through large plastic covers at the rear of the machine. One-person screen change in minutes for all but the largest Sizers.
Maximum Flexibility: The MSizer is available in three model sizes up to 6 screen decks. Application-specific accessories like screen cleaning aids, screen deck heating, automatic screen tension monitoring and wear protection optimize the Sizer for your production process.
Environmentally Friendly: Low carbon footprint as the machine requires 50% less energy compared to equivalent solutions. In addition, the MSizer consumes fewer resources in manufacturing, as it is a compact machine with long-lasting meshes
High Efficiency: Minimized energy consumption of the drives and low maintenance costs.
